Brand Name : | XINKE |
Certification : | CE, ISO9001:2000 |
Price : | USD 10000-200000 Per Unit |
Payment Terms : | L/C, T/T |
Supply Ability : | 10 Units Per Months |
Delivery Time : | 90-180 Working Days |
HY13 40T Hydraulic Press for Aluminum Die Casting
Features:
Application:
Suitable for the process of rotors of motors
Technical Data:
Item | Unit | HY13-40 | ||
Range of Motor Rotor die casting | Micro-motor | |||
Mould Clamping Force | KN | 400 | ||
Ejecting force | KN | 100 | ||
Pressurization force | KN | / | ||
Cutting force | KN | / | ||
Working pressure of medium | Mpa | 25 | ||
Stroke of slider | mm | 320 | ||
Injection piston stroke | mm | 150 | ||
Opening daylight | kg | 520 | ||
Aluminum injection capacity | kg | / | ||
Speed of slider | Descend | mm/s | 65 | |
Working | mm/s | 10 | ||
Return | mm/s | 105 | ||
Injection speed | Slow working | mm/s | 155 | |
Quick working | mm/s | 600 | ||
Return | mm/s | 405 | ||
Size of worktable | L.R. | mm | 460 | |
F.B. | mm | 400 | ||
Motor power | Kw | 5.5 | ||
Overall size of machine | L.R. | mm | 1750 | |
F.B. | mm | 1600 | ||
Height above the floor | mm | 2480 | ||
Machine weight | kg | 2500 |
![]() |
